Size(cylinder Dia.×cylinder Length)  (m)

Φ1.2×10

Φ1.5×14

Φ1.8×18

Φ2.0×20

Φ2.2×22

Φ2.4×24

Φ2.6×26

Φ2.8×28

Φ3.0×30

Φ3.5×30

Φ3.8×30

Capacity (t/h)

2-3

3-5

5-6

8-10

10-14

14-16

16-20

20-24

24-30

30-35

35-40

Rotary Speed (r/min)

5.4

4.7

4.15

3.75

4

3.6

3.5

3.2

3

3.4

3.4

Slope (degree)

1.5-2.5

Air-in temperature (℃)

80-350

Dischanging moisture (%)

1-4

Motor

Type

Y160M-6

Y180L-6

Y200L2-6

Y225M-6

Y280S-6

Y280M-6

Y315S-6

Y315M-6

Y355M-6

Y335M2-6

Y355L1-6

Power(kw)

7.5

15

22

30

45

55

75

90

160

185

220

Dimensions (L.×W.×H.) (mm)

12500
×2000
×2400

15440
×2375
×3110

19600
×3200
×3400

21750
×2820
×3445

24300
×3380
×4410

26000
×3430
×4200

27500
×3400
×4400

30800
×4200
×4550

33000
×4250
×5000

33000
×4800
×5900

34000
×5200
×6640
